Fully automatic stand zipper doypack pouch bean dry fruit peanut cashew nuts packing machine
Application of nuts packing machine
The machine is suitable for packaging granular materials, such as coffee beans, potato chips, nuts, peanuts, cashews, walnuts, spaghetti, pet food, candy, gummy bears, beef cubes, popcorn, meatballs, dried fish, wolfberries, olives , Dried fruits, tea, melon seeds, rice, etc.
Specification of nuts packing machine
| Packing speed |
20-60 bags/min (depending on the weight of the material) |
|
Measuring range |
10-1500g (depending on the characteristics of the material) |
|
Bag width |
120-250mm |
|
Bag length |
80-360mm |
|
Film materials |
PP, PE, PVC, PS, EVA, PET, PVDC+PVC, OPP+composite CPP, etc. |
|
Power |
380V, 50/60Hz, 8.5kw |
|
Gas consumption |
1.0m³/min |
|
Dimension |
4070(L)*2820(W)*3700(H)mm |
|
Machine weight |
1300kg |
Features of nuts packing machine
1. 8-station design, can automatically complete a series of processes such as bag taking, bag opening, metering, blanking, sealing, etc.
2. High quality and performance, the frame is made of 1.5mm thickness 304# stainless steel.
3. Intelligent PLC control, fast and stable operation of the machine.
4. The touch screen is used to set packaging parameters, supports multiple languages, and the operation is simple and easy to understand.
5. With electric eye detection function, automatic stop operation without bag.
6. The host adopts a new frame design, which occupies a small area and is easy to detect and maintain.
7. Independent temperature PID controller.
